GF S Air-Cooled Welding Laser Welding Machine
◆1.5-3 [kW] Laser power
◆2 [mm] Max diameter of filler wire
◆6 [mm] Max thickness of sheet
◆10 [m] Max length of optical fiber
◆1 [year] Warranty period
Main Parameters | Model | ||
| 1500HWM | 2000HWM | 3000HWM |
(kW) | 1.5 | 2 | 3 |
Laser Wavelength (nm) | 1080±10 | 1080±10 | 1080±10 |
Thickness of Welding Sheet (mm) | ≤3mm | ≤4mm | ≤6mm |
Diameter of Filler Wire (mm) | 0.8-1.6 (standard) | 0.8-1.6 (standard) | 0.8-1.6 (single-wire) 1.6 and 2 (double-wire) |
Machine Cooling | Water cooling | Water cooling | Water cooling |
Optical Fiber Length (m) | 10 | 10 | 10 |
Overall Dimensions (L*W*H, mm) | 954*715*1080 | 954*715*1080 | 1210*715*1200 |
Power Supply | Three-phase 380V, 50Hz/60Hz (custom-made) | ||
Unlike traditional welding, laser welding has less thermal input, resulting in hard-to-deform workpiece, higher welding strength than parent materials sometimes, as well as pleasing seams with no further polishing. Due to no demand on experience, it is easy to recruit at lower costs.
* Save 2 welders at least
* Efficiency gains by 3-10 times
* Basically no consumables, and maintenance-free
This small handheld welding gun will keep workers from tiring after long work. Its long optical fiber breaks through the limitation of worktable, so, welding can be done in multiple locations and angles.
* Weight of welding gun≤0.7kg
* Max length of optical fiber: 10m
* Work at will within the scope of 360°
Automatic single- and double-wire feeder are offered for your selection. Users can feed single wire or use two wires of different diameters and/or types when related spare parts are not changed. For the latter, it is easy to switch between wire sizes or between types.
* Single-wire feeder
0.8-1.6mm (standard)
* Double-wire feeder
Single-wire mode: 0.8-1.6mm
Double-wire mode: 1.6mm and 2mm
The machine body and auto wire feeder are equipped with 4 universal wheels respectively. They will be pushed easily when needed.
* Universal casters to enable 360° movement
* No need for fixed station and weld anywhere
Handheld laser welding machine is gradually replacing the traditional modes and developing into a popular device at home and abroad. For businesses in need, it can yet be regarded as a long-term investment with small investment but great results.
