GF3015H Series Double Exchange Platforms Sheet Laser Cutting Machine
◆ 1.5-12 [kW] Laser power
◆ 3050*1530 [mm] Max sheet size
◆ 130 [m/min] Max no-load speed
◆ 700 [kg] Max load of platforms
◆ 2 [years] Warranty period
Main Parameters | Model |
| 3015H |
Laser Power (kW) | 1.5-12 |
Working Area (L*W, mm) | 3050*1530 |
X/Y-axis Positioning Accuracy (mm/m) | ±0.05 |
X/Y-axis Repositioning Accuracy (mm) | ±0.02 |
Max No-load Speed (m/min) | 130 |
Max Load of Platforms (kg) | 700 |
Overall Dimensions (L*W*H, mm) | 8450*2270*2260 |
Power Supply | Three-phase 380V, 50Hz/60Hz |
In our self-developed CNC system, the fly cutting, obstacle avoidance at idling as well as leapfrog of cutting head are provided. Due to its instant response, the machine works at lightning-fast speed.
* Sheet thickness: 1-40mm
* Max cutting speed: 55m/min
Its aviation-grade AL alloy beam has high dynamic performance even at fast speed. On double exchange platforms, the cutting, loading and unloading run in parallel. With that, waiting time will be sharply reduced, so as to speed up your work.
* Max speed: 130m/min
* Max acceleration: 1.2G
To enable smoke-free effects, this model has fully-enclosed lift door and intelligent negative-pressure dust removal system that can control air vents in real time.
With safety monitoring system, users will have a panoramic view of all work processes and minimize blind area. So, workers are well protected. Cutting becomes more safe and stable.
* Large-sized display screen
* 720° all-round safety monitoring
We have recently refined container stuffing plans. Two 3015H can be put in one 40HQ standard container with no need to tear down sheet metals and beam. So, our loading will be at lower costs but higher efficiency.
This classic model has gone through technical upgrades, which always keeps stable at work and is in great favor as one of best-selling machines by users from household appliances, kitchenware and sanitary wares, chassis cabinet, billboards, elevator manufacturing, etc.
