GF3015C (Combo) Series Affordable Sheet & Tube Laser Cutting Machine
◆ 1.5-6 [kW] Laser power
◆ 3050*1530 [mm] Max sheet size
◆ 20~220 [mm] Scope of tube size
◆ 100 [m/min] Max no-load speed
◆ 2 [years] Warranty period
Main Parameters | Model |
| 3015C |
Laser Power (kW) | 1.5-6 |
Working Area (L*W, mm) | 3050*1530 |
X/Y-axis Positioning Accuracy (mm) | ±0.05 |
X/Y-axis Repositioning Accuracy (mm) | ±0.02 |
Max No-load Speed (m/min) | 100 |
Diameter of Round Tube (mm) | 20-220 |
Tube Length (mm) | 500-6000 |
Max Load of Platform (kg) | 700 |
Overall Dimensions (L*W*H, mm) | 8500*3740*2100 |
Power Supply | Three-phase 380V, 50Hz/60Hz |
As a dual-purpose machine, it can cut both sheet and tube, requiring much less space and early investment. Start-ups with insufficient economic power or small workshop can also afford it.
* Need 50%+ less footprint
* Purchase costs halved at least
Its core components below are self-developed by us. Thanks to their superior interconnection, you will surely face low failure rate and user-friendly maintenance.
* Intelligent control system
A sea of cutting crafts and customization as needed
* Laser generator
High electro-optical conversion rate
* Laser cutting head
Autofocus and high degree of safety
With pneumatic self-centering chuck, tubes of different shapes are usually clamped tightly at high precision. Short tailing is made possible.
* Max diameter of tube: 220mm
* Max length of tube: 6000mm
* Max no-load speed: 100m/min
* Max acceleration: 1G
The machine is convenient to load and unload sheet and tube from front, rear and both sides. For users, they will get a whole picture of cutting process and solve possible faults in time. No unwanted downtime anymore.
3015C is ideally fit to cut thin sheet (≤20mm) and small tube (max diameter: 220mm). We recommend it to household appliances, kitchenware and sanitary wares, chassis cabinet, billboards, elevator manufacturing, etc.
